Scale: 1 inch to 60 feet
A longitudinal section and ‘alternative elevation’ of proposed extension to the Capuchin Friary, Kilkenny. The ‘alternative elevation’ drawing shows the portion of the Friary fronting onto Walkin Street. The section shows the tertiary office, the choir and community room. The plan is titled ‘Drawing No. 5’.

Plan of ‘general arrangement of power house’ for the installation of electric lighting at the Capuchin Friary, Kilkenny. The name of the engineering firm is not given. With blueprint of the ‘stands for Vs type cells to be installed’.

Scale: ‘½ scale’
Sketches of proposed memorial ‘to be erected by Mr. Geary’ in the Church of St. Francis. Three alternative sketches or ‘schemes’ of the memorial statue or shrine to Our Lady are given by John J. Robinson & R.C. Keefe, architects, 8 Merrion Square, Dublin. With manuscript annotations re the costs of the work and installation.

Scale: ‘1/8 scale’
Sketch plans (with sections) of proposed schemes for alterations to the sacristy of the Church of St. Francis, Kilkenny, by John J. Robinson & R.C. Keefe, architects, 8 Merrion Square, Dublin. The sacristy is bordered by reception rooms, altar servers’ rooms, confessionals and a vestments’ press. See related correspondence at CA KK/2/4/16.

Scale: ‘1/8 inch’.
Side elevation of proposed alterations to the exterior of the Church of St. Francis by John J. Robinson & R.C. Keefe, architects, 8 Merrion Square, Dublin.

Scale: ¼ inch to 1 foot for plan; 5ft to 1 mile for site map
Plan sheet for internal alterations at the Capuchin Friary, Kilkenny, to accommodate the novitiate building. Plan by Sylvester Bourke, architect, 79 High Street, Kilkenny. The novitiate is situated between the Friary and the Church of St. Francis. Includes plan and sections of bedrooms, the recreation hall and the study hall. With a site map insert showing the Friary bounded by Walkin (Friary) Street and Pennyfeather Lane. Sheet number: LO.14 a/1. See also CA KK/2/4/25.

Scale: ¼ inch to 1 foot
Technical plan for choir room accommodation and ventilation at the Capuchin Friary, Kilkenny by Sylvester Bourke, architect, 79 High Street, Kilkenny. The drawing was supplied to the guardian of the Kilkenny Friary. Sheet number: LO.14 (A). Includes sections and elevations of choir ceiling, installations (kneelers) and second floor plan. It is noted that ‘the treatment of the arms of the Capuchin Order as incorporated in the extract grid is to special detail and template and will be supplied as necessary’.
